Application:
Various Types of Solid-Like Shape of the Product – such as: Nougat, Pineapple Cake, Cookies, Peanut Candy, Meat, Chocolate, Candied Fruit, Toothbrushes, Syringes, Mouse Pads, Mask, Wet Wipes, Metal Parts, PIZZA Crust, Bread, Moon Cake, Instant Noodles, Meat, Soap, Rice, Seaweed…etc.
Features:
- Twin reels with quick release locks.
- Automatic bag length adjustment by PLC system.
- Auto-stop avoids film breakage & film running out.
- Automatic bag length monitoring and adjusting.
- Equipped with a photocell made in Germany avoiding film-cutting error.
- Complete airtight sealing.
- Touch screen for operator interface.
- Connected parts with product made by stainless steel.
Technical specification:
| Model | HW-264A | HW-266A |
| Packing Style | Pillow Type | Pillow Type |
| Pouch Material | PET/CPP, PET/OPP | PET/CPP, PET/OPP |
| Max. Film Width | 400mm | 600mm |
| Pouch Size (Length) | 100~320mm | 100~320mm |
| Pouch Size (Width) | 20~120mm | 70~230mm |
| Pouch Size (Height) | 5~60mm | 5~60mm |
| Operating Speed | 100 pouches/min | 90 pouches/min |
| Power Supply | 220V single phase 50/60HZ (3 phase as an option) | 220V single phase 50/60HZ (3 phase as an option) |
| Weight | Approx. 900KG | Approx.900KG |
